What’s in the Box
| Standards & Performance | |
|---|---|
| Nominal Load Impedance | 4-Ohm |
| Maximum Peak Power Handling - Watts | 450 Watts with packaged crossover network |
| Frequency Response | 101 Hz to 34 kHz/ 850 Hz to 33kHz - with inline packaged crossover network |
| Crossover Frequency | 6,200 Hz - Acoustic / 4,800 Hz - Electric |
| Continuous Power Handling (RMS) - Watts | 100 Watts with packaged crossover network |
| CTA2031 Compliant | Yes |
| SPEAKER MATERIALS | |
| Wire Terminals | Lug Type |
| Voice Coil wire | Copper |
| Voice Coil Type | Single Voice Coil |
| Voice Coil Material | Glass Imide |
| Surround Type | Rolled |
| Surround Material | Rubber |
| Magnet Weight | 4.5 oz |
| Magnet Material | Ferrite |
| Damper | Aramid Fiber |
| Custom Fit Basket | Yes |
| Cone Material | Carbon and Mica reinforced Injected Molded Polypropylene - IMPP |
| Basket Material | Resin |
| SPEAKER FEATURES | |
| Unit Size | 3-1/2" / 25mm - Tweeter |
| Unit Shape | Round |
| Tweeter | 25mm |
| Mounting Depth | 1-3/8 inch(es) |
| Cut Out dimensions | 3 inch(es) |
| Standards & Performance | |
| System-Type | Coaxial 2-way |
| Sensitivity (1W/1m) | 85 dB |
| Tweeter | |
| Type | Balance Dome |
| Magnet Weight | 0.1 oz |
| Magnet Material | Neodymium |
| Diaphragm Material | Polyetherimide (PEI) |
