| Price | $250.00 |
| Savings | $20.01 |
| Our Price |
$229.99 Sale Ends : December 31, 2025
-- OR --
$57.50 Sale Ends : December 31, 2025 In 4 installments with
On Sale
|
| Key Features | |
|---|---|
| System Type | Component Subwoofer |
| Sensitivity (1W/1m) | 76dB |
| Frequency Range | 20 Hz to 3.4 kHz |
| CTA-2031 Compliant | Yes |
| Warranty | 1 Year |
| Continuous Power handling (RMS) - Watts | 350 Watts |
| Maximum Peak Power Handling - Watts | 1300 Watts |
| Nominal Impedance - OHM | 4 |
| Speaker Grill | Sold separately (UD-10GL) |
| Build | |
| Shape | Round |
| Size | 10" |
| Cone Material | IMPP - Aramid Fiber |
| Center Cap Material | ABS |
| Surround Material | Rubber |
| Surround Type | Rolled |
| Basket Material | Stamped Metal |
| Magnet Material | Ferrite |
| Magnet Weight | 43.4 oz |
| Voice Coil Type | Single Voice |
| Voice Coil Bobbin | Glass imide |
| Voice Coil wire | Copper |
| Damper | Aramid |
| Gasket | PP |
| Wire Terminals | Push Type |
| Unit Size (Dimensions) | 10-1/2" |
| Mounting Depth | 3-1/4" |
| Cut Out dimensions | 9" |
| Equivalent Compliance (VAS) [L] | 16.1 |
| Free Air Resonance (Fs) [Hz] | 37 |
| Total Speaker "Q" (Qts) | 0.8 |
| Linear Excursion (Xmax) [mm] | 8.3 |
| Recommended Sealed Box Volume [L] | 17 |
| Port Box volume [L] | 17 |
| Port Length | 7-1/2" |
| Port Diameter | 3" |
